The SP520F Walk-Behind Floor Scrubber is a battery-powered industrial floor cleaning machine designed for routine maintenance of warehouses, factories, workshops and commercial facilities. Featuring a 520 mm cleaning width, a 68 L solution tank, a 70 L recovery tank and a single 19-inch nylon disc brush, it combines mechanical floor scrubbing with wastewater recovery. Its 24V battery system, mechanical brush lifting and compact design provide a practical solution for daily indoor floor cleaning.
The SP520F is a walk-behind floor scrubber designed for routine cleaning of industrial and commercial indoor floors.
Equipped with a single 19-inch nylon disc brush, a 550 W brush motor and a 600 W vacuum motor, the machine combines mechanical floor scrubbing with wastewater recovery for regular facility maintenance.
Its 68 L solution tank and 70 L recovery tank provide water storage capacity for daily cleaning operations. The compact body, mechanical brush lifting system and 24V lead-acid battery make the SP520F suitable for warehouses, manufacturing workshops, retail facilities and commercial buildings.
Low-voltage and wastewater alarms help operators monitor machine conditions, while an optional high-pressure spray gun is available for additional washing requirements.
A nylon disc brush provides mechanical scrubbing for routine industrial and commercial floor cleaning.
The dedicated brush motor powers the single-disc cleaning system for daily floor maintenance.
The wide squeegee helps collect wastewater during wet floor cleaning operations.
The vacuum motor provides suction for wastewater recovery during floor scrubbing.
Manufacturer-listed noise level for routine indoor cleaning applications.
A mechanically operated brush lifting system provides straightforward brush positioning during cleaning.
The SP520F is intended for routine floor cleaning where compact walk-behind equipment, mechanical scrubbing and wastewater recovery are required.
Suitable for regular scrubbing of warehouse floors, storage spaces and indoor material handling areas.
Helps maintain workshop floors and production areas during routine facility cleaning.
Practical for cleaning corridors, common areas and other suitable indoor commercial floors.
Supports scheduled wet cleaning of retail stores and commercial floor surfaces.
Useful for cleaning storage buildings and indoor distribution areas with regular maintenance needs.
Suitable for routine floor maintenance in educational, administrative and institutional buildings.
| Model | SP520F |
|---|---|
| Machine Type | Walk-Behind Floor Scrubber |
| Cleaning Width | 520 mm |
| Squeegee Width | 830 mm |
| Manufacturer-Listed Cleaning Efficiency | 2500 m²/h |
| Solution Tank Capacity | 68 L |
| Recovery Tank Capacity | 70 L |
| Working Time | Approx. 3.5–5 Hours |
| Noise Level | ≤55 dB (Manufacturer-Listed) |
| Machine Weight | 200 kg |
| Brush Motor Power | 550 W |
|---|---|
| Vacuum Motor Power | 600 W |
| Brush Quantity | 1 |
| Brush Size | 19 inches |
| Brush Material | Nylon |
| Brush Pressure | 50 kg (Manufacturer-Listed) |
| Brush Lifting | Mechanical |
| Low-Voltage Alarm | Yes |
| Wastewater Alarm | Yes |
| Optional High-Pressure Spray Gun Power | 150 W |
| Power Source | Battery Electric |
|---|---|
| Battery Type | Tianneng Lead-Acid Battery |
| Battery Voltage | 24 V |
| Battery Capacity | To Be Confirmed |
| Overall Length | 1200 mm |
| Overall Width | 830 mm |
| Overall Height | 1200 mm |
| Overall Dimensions (L × W × H) | 1200 × 830 × 1200 mm |
| Wheel Material | Aluminum Alloy / Polyurethane (Manufacturer-Listed) |
| Steel Body Thickness | 4 mm |
| Molded Plastic Thickness | 5 mm |
Important inspection points for the SP520F include machine assembly, brush motor operation, vacuum recovery performance, mechanical brush lifting, water tank sealing, battery connections and electrical controls.
Functional checks before shipment help verify the main floor scrubbing and wastewater recovery systems. Specific inspection procedures can be confirmed according to production and order requirements.
Warranty terms are provided according to the final machine configuration and order conditions.
Replacement and maintenance parts may be supplied according to the agreed after-sales service arrangements.
Operating and maintenance guidance can be arranged according to customer requirements.
Remote technical assistance may be available according to the agreed service terms.
